VOX AC10C1 Parts List : SAFETY CRITICAL COMPONENT.

EXP=EXPLODED VIEW Item No

Code Part Name Location EXP Reference QTY

530000003368 PCB ASSY JACK COM AC10C1 JACK 1

530000002888 JACK SOCKET(MONO) JACK J1 1

530000002069 SPECIAL WASHER 18.9X18X JACK J1 INPUT 1

530000003369 PCB ASSY LED COM AC10C1 LED 1

530000003370 LED HOLDER D9.25X13.4 ME LED LED HOLD 1

530000003371 LED CY 5X8.6X16 RD LED LED1 1

530000003372 PCB ASSY MAIN COM AC10C1 MAIN 1

530000003373 DIODE DB101-C 50V 1A MAIN D1 1

530000003374 DZ 1W 18V 5% 1N5931B AT MAIN D2, D3, D6, D9 4

530000002089 DIODE IN4007-F AT MAIN D4, D5, D7, D8 4

530000003375 RCF 2W 6.8R 5% ATW MAIN R4 1

530000003376 RMF 3W 33R 5% AT MAIN R5 1

530000002633 RWR 5W 1K 5% SQZ RL MAIN R99 1

530000002438 FUSE 200MA 250V EU/UK/AUS/SKOR MAIN F1 1

530000002094 FUSE T6.3A 250V 5X20 UL MAIN F2 1

530000003377 VR ROTARY A500KX1 20% V MAIN VR1 1

530000002631 VR ROTARY A1MX1 30% V MAIN VR2, VR3 2

530000001882 VR Rotary B20KX1 20% V MAIN VR4 1

530000002083 VR ROTARY A500KX1 20% V MAIN VR5 1

530000002448 SPECIAL WASHER 23.8X18X MAIN J2 INPUT 1

530000003378 PHONE JACK F 4P 6.4X16.5 MAIN J4 1

530000003379 MOSFET N-CH 500V LND150N MAIN Q1, Q4 2

530000003380 IC ASIC NJM2115M DMP8 MAIN U1 1

530000003381 IC REGULATOR LM2940CS-5. MAIN U3 1

530000003382 SOCKET 9PIN 500V WHITE MAIN V2, V3 2

530000003383 PCB ASSY TUBE COM AC10C1 TUBE 1

530000003179 RWR 5W 120R 5% SQZ RL TUBE R8 1

530000002060 SOCKET 9PIN 500V D=22 TUBE V1, V4 2

530000003384 PCB ASSY ERP EU UK AC10C EU UK 1

530000002089 DIODE IN4007-F AT EU UK D1, D3 2

530000002636 DIODE 1N4148T AT EU UK D4, D15 2

530000003385 TR 2N3904TA RLT EU UK Q1, Q3 2

530000003178 RWR 5W 47K 5% SQZ RL EU UK R21 1

530000003386 RELAY 5V 80MA SPST BRT3- EU UK K1 1

530000003180 PHOTOCOUPLER EL817 EU UK S1 1

530000003387 SW SLIDE SPDT 12V 0.1A EU UK SW2 1

530000003388 PCB ASSY REVERB COM AC10 (DATA) REVERB

530000003389 CRYSTAL 12.000MHZ HC-49U REVERB X1 1

530000003390 IC ASIC TL064ACD SO16 REVERB U1 1

530000001874 Logo 45X11 1 1

530000002046 VENT-LARGE PP BLK 94V0 2 1

530000003392 SCREW MACH O-CS 4X20 CR LCS NI 3 4

530000002076 HANDLE-TOP 187X25.8X15.8 4 1

530000002445 T5706 VOX 10 16OHM[OIC] 6 1

530000003394 WOOD CAB 520X210X365 MDF+PB 14 1

530000002067 CLIP TUBE 34X27X68 METAL 15 2

530000002081 VACUUM TUBE COMPACTRON EL84 17 2
