= SAFETY CRITICAL COMPONENT.
EXP=EXPLODED VIEW Item No
C1 C2 CH C1 C2 CH
530000002137 PCB ASSY SET AC15C1 PCB ASSY SET 1 0 0
530000002705 PCB ASSY SET AC15C2 PCB ASSY SET 0 1 0
530000003412 PCB ASSY SET AC15CH PCB ASSY SET 0 0 1
530000003413
PCB ASSY ATT AC15CH PCB ASSY ATT SET
001
530000001903 3 PIN ST. WAFER INPUT TCN2 1 1 1
530000001870 JACK MONO 4P P6.4X16.5(3343) INPUT JS1, JS2 2 2 2
530000002116 Cable WIRE-CONN 2P P2.5 #26 LED TCN1 1 1 1
530000002092 DIODE DZ 1.3W 27V 7% AT MAIN D2, D5 2 2 2
530000002089 DIODE DIODE IN4007-F AT MAIN
D10, D3, D4, D6,
D7, D8, D9
777
530000001903 3 PIN ST. WAFER MAIN CON2, CON3, CON4 3 3 3
530000001901 2P ST.WAFER MAIN CON5 1 1 1
530000002054 5P ST.WAFER MAIN J1,J2 2 2 2
530000001900 SPADE TERMINAL 6.3X0.8 MAIN
J11, J17, J18, J19,J20,
J21,J22,J23
888
530000001917 COIL FERRITE BEAD INDUCTOR MAIN
R47, R48, R50, R53, R59,
R62, R63, R64
888
530000002082 RMOF 1W 2R2 5% AT MAIN F3 1 1 1
530000002064 IC IC NJM2147D#ZZZB MAIN U1, U2, U3, U4, U5 5 5 5
530000002083 VR VR ROTARY A500KX1 20% V MAIN VR1, VR2,VR9 3 3 2
530000003414 VR VR ROTARY 500KAX2 20% V L=15 MAIN VR9 0 0 1
530000002084 VR VR ROTARY A1MX1 20% V MAIN VR3, VR4 2 2 2
530000002085 VR VR ROTARY B100KX1 20% V MAIN VR5 1 1 1
530000002086 VR VR ROTARY C2.2MX1 20% V MAIN VR6 1 1 1
530000002087 VR VR ROTARY B500KX1 20% V MAIN VR7 1 1 1
530000002088 VR VR ROTARY B220KX1 20% V MAIN VR8 1 1 1
530000002066 FUSE HOLDER MAIN F1, F2 2 2 2
530000002108 CABLE WIRE-SHIELD 9P P2.54 #20 MAIN J10, J8 2 2 2
530000002093 FET MOSFET N-CH 500V 0.001A MAIN MF1 1 1 1
530000001914 FET FET J174_NL P-CHANNEL MAIN Q1 1 1 1
530000001904 TR 2SC2910 HFE200 MAIN Q2 1 1 1
530000001900 SPADE TERMINAL 6.3X0.8 OUTPUT J14, J16, J24, J25 4 4 4
530000001870 JACK MONO 4P P6.4X16.5(3343) OUTPUT J13, J15 2 2 2
530000001903 3 PIN ST. WAFER SWITCH TCN3 1 1 1
530000001917 COIL FERRITE BEAD INDUCTOR SWITCH R10, R13, R16 3 3 3
530000001872 JACK STEREO 6P P6.4X16.5 SWITCH J3 1 1 1
530000001900 SPADE TERMINAL 6.3X0.8 TUBE2 J12, J7 2 2 2
530000002056 9-PIN WAFER TUBE2 J9 1 1 1
530000002060 SOCKET 9PIN 500V D=22 TUBE2 V4, V5 2 2 2
530000001903 3 PIN ST. WAFER TUBE CON1 1 1 1
530000002054 5P ST.WAFER TUBE J4, J5 2 2 2
530000002056 9-PIN WAFER TUBE J6 1 1 1
530000002090 DIODE BRIDGE 50V 4A TUBE D1 1 1 1
530000002059 SOCKET VALVE 9P 500V TUBE V1 1 1 1
530000002060 SOCKET 9PIN 500V D=22 TUBE V2, V3 2 2 2
530000001912 IC TL072CP DUAL FET OP ATT
U1
00
1
530000003415
RWR 3W 1R 5% SQZ RL MINI
ATT
R8
00
1
530000003416
RWR 10W 3.3R 5% SQZ RL
ATT
R9, R10
00
2
530000003417
RWR 5W 2.7R 5% SQZ RL MI
ATT
R14, R15
00
2
530000003418
RWR 5W 1.8R 5% SQZ RL
ATT
R16
00
1
530000003419
RWR 5W 2.2R 5% SQZ RL MI
ATT
R30
00
1
530000003420
SW ROTARY 3P3T DC30V 1A
ATT
SW1
00
1
530000002637
DZ 1/2W 15V 5% TEMIC AT
ATT
D5, D6
00
2
530000002133 WIRE-RCA 2P #26 UL2562 1000MM 1 0 1
530000002115 WIRE-RCA 2P #26 UL2562 1400mm 0 1 0
530000002103 CONN WIRE UL1007 #26 3PO CASING 3P FOOT 1 1 1
530000002105 WIRE-GND 1P #18 UL1015 CASING 1P GND 1 1 1
530000002104 WIRE-CONN 1P #18 UL1015 CASING 250 G 1 1 1
530000002111 WIRE-SHIELD 3P P2.5 #26 CASING 3P REVERB 2 2 2
530000002109 WIRE-SHIELD 3P P2.5 #26 CASING 3P WIRE 1 1 1
530000002114 WIRE-CONN 5P P2.5 #24 CASING 5P WIRE 1 1 1
530000002117 WIRE-SHIELD 5P P2.5 #24 CASING 5P WIRE S 1 1 1
REVERB
ReferencePart Number Category Part Name Location
EXP
CASING
QTY
To Next Page
