23
ENGLISH
T50T50
SPECIFICATION
1. GENERAL SECTION:
Power Supply AC 110V,60Hz (Taiwan)
AC 220V,60Hz (Korea)
AC 230V,50Hz (Europe, China)
Power Consumption 2Watts
Dimensions
435(W) x 372.5(D) x 121.5(H) mm
Weight 3.9Kg
2. STANDARD TEST CONDITION:
Ambient Temperature 23 +/- 2 degC
Relative Humidity 65% +/- 5%
NOTE
:Measurements can be carried out between 5
degC to 35 degC and 45% to 85% relative humidity.
3. TURNTABLE SECTION:
Type 2-speed full-auto
Motor DC motor
Driving Method Belt drive
Turntable Platter
296mm dia. Aluminum diecast
Speeds 33 1/3 and 45 RPM
Wow and Flutter
Less than 0.25% (WTD) at 3KHz (JIS)
Signal to Runble Ratio More than 50 dB (DIN-B)
Signal to conductive More than 50 dB
noise ratio
Speed Tolerance Normal 2980~3000Hz,
Limit 2940~3090Hz
USB Function USB REC. Function
A/D,D/A 16BIT 44.1KHz or 48KHz
USB SELECTABLE
Computer interface USB 1.1 COMPLIANT
WINDOWS XP/ Vista or
MAC OSX
4. TONEARM SECTION:
Type Dynamic balanced straight
shaped w/soft damping control
Effective Arm Length 221.5 mm
Overhang 19 mm
Offset angle 25.61°
Tracking Error Angle 3 degree or less
Stylus pressure
Rotation movability (1-rotation 4g)
adjustment method
Applicable cartridge
14.5~20g (Including Head shell)
weight
Anti-skating 0~3g
adjustment range
Arm lifter Oil damper type
5. Cartridge Section
Type Moving magnetic cartridge
Stylus Diamond stylus
Channel Separation More than 15dB at 1KHz
(HP-4005)
Channel Balance Within 2.5dB at 1KHz
(HP-4005)
PHONO Output Level 1.5~3.6mv at 1KHz 5 cm/sec
(HP-4005)
LINE Output Level
129~313mv at 1KHz 5 cm/sec
(HP-4005)
RIAA 20~20KHz +1/-3dB
Tracking Force 3.5 ±1 g
