VPC ICON - SECTION 9 TROUBLESHOOTING; ITA FRAME ALIGNMENT ISSUES

ICON USER’S MANUAL: SECTION 9 VIRGINIA PANEL CORPORATION
9-1 For the most current information available, visit www.vpc.com
6/7/18
Forceful engagement of the Receiver and the ITA
will result in serious damage to multiple parts of
the system (Modules, Receiver, ITA and Contacts)!
ITA Frame is not lined up when in the process of engagement with Receiver
• This may indicate that the ITA was dropped and is out of alignment or that a module is not mating with its intended module.
• Remove and inspect the ITA for alignment
• Check for foreign objects/tools
• Inspect the matching of modules - Power ITA Module to mate with Power Receiver Module, etc.
• The keying pin locations do not mate.
• The handle is installed wrong (“ITA ICON COVER INSTALLATION”).
TROUBLESHOOTING
