RCVC 3000 - Red Circle Valve Controller
Installation, Operation, Maintenance Manual
Table 1.0 RCVC Specications
Power Supply
Power Supply 19-30 VDC
RCVC Module Current 50mA max
RCVC Total Assembly Rating 2A max
Onboard Fuse Limitron: FNQ-R-2 600VAC IR 200kA
Digital Outputs
Congurable Solenoids 3 Max
Voltage 24 VDC
Load Current (max) 1.0 Amps
Digital Inputs
No. Digital Inputs 2 (Congurable)
Voltage 24 VDC
Input Current 5.0 mAmps
Digital Outputs
No. Digital Outputs 3 (Open Sol, Close Sol, Auxiliary)
Voltage 24 VDC
Load Current (max) 250 mAmp
Analogue Inputs
No. Analogue Inputs 2 (Feedback, Command)
Input Type Current / Voltage
Voltage Input Range 1 - 5.0 VDC
Voltage Input Impedance 100 kOhms
Current Input Range 4 - 20 mA
Current Input Impedance 300 Ohms
Resolution 1 in 3600
Analogue Outputs
Output Type Current / Voltage
Voltage Output Range 4.0 - 20.0 ma / 0 - 3.0 VDC
Resolution 1 in 3600
Solenoid Ohms
AAA 58 - 65 Ohms
Asco 43 - 54 Ohms
