EN - 12
Replace a handset battery installation
The handset battery is pre-installed. To replace
the handset battery, follow as shown below.
1. Use a narrow object to pry open the screw
cover and remove the screw with cross head
screwdriver. Then, insert a 5 mm standard flat
head screwdriver in the provided slot and gently
open the handset cover.
2. Unplug the battery connector from the
socket and then remove the battery from the
handset battery compartment.
3. Plug the battery connector securely into the
socket inside the handset battery compartment.
Place the battery with the label THIS SIDE UP
facing up and the wires inside the battery
compartment.
THIS SIDE UP / CE CÔTÉ VERS LE HAUT
Battery Pack / Bloc-piles :
BT183342/BT283342 (2.4V 400mAh Ni-MH)
WARNING / AVERTISSEMENT :
DO NOT BURN OR PUNCTURE BATTERIES.
NE PAS INCINÉRER OU PERCER LES PILES.
Made in China / Fabriqué en chine CR1535
THIS SIDE UP
4. To replace the handset cover, align all
the tabs on the handset cover against the
corresponding grooves on the handset, then
firmly push downward until all the tabs lock
in the grooves. Then install the screw.
• There may be a risk of explosion if a
wrong type of handset battery is used. Use
only the supplied rechargeable battery
(
BT164392/BT264392
) or replacement battery
(
BT264392
). To order a replacement, call
1-888-907-2007.
• FCC ID is shown on the back of the cordless
handset body after the handset cover is
removed.
• Dispose of used batteries according to the
information in The RBRC® seal.
