Base Installation Instructions
Put machine flat on table first. Install base in machine back cover bottom as arrow direction in the figure, and
make the positioning hole on top of V cover of base aligned with the positioning raised stand on the bottom of
machine back cover, then fasten screws. (notice that base has to be adjusted at figure status, otherwise it
cannot be installed in.)
Remark: The actual base and machine appearance may be different from pictures; please refer to the actual
device.
Base
Screws
