1 Foreword
Right/left/front/rear
The terms refer to the main travel direction.
• 1: Left
• 2: Right
• 3: Front
• 4: Rear
• Main travel direction: seat position facing the drive unit (A).
• Side travel direction: seat position facing the loader unit (B).
B
A
Fig. 1 Direction definition
21
4
3
