3-2 BA D24 en/us* 1.0 * D24_1_0_300.fm
3 Introduction
Fig. 3 (symbolic representations)
5
7
8
9
3
1
4
2
6
nr. Designation nr. Designation
1 Drive unit 6 Tilt cylinder
2 Loader unit 7 Skip
3 Articulation 8 Swiveling console
4 Steering cylinder 9 Cab
5 Swiveling cylinder -- --
