Putting into operation 4
Document box
The Operator’s Manual is stored in the document box under the seat.
12 V connection
A 12 V power outlet A is located beside the starter.
4.2 Overview of control elements
This chapter describes the controls, and contains information on the
function and handling of the indicator lights and controls.
The pages stated in the table refer to the description of the controls.
Fig. 83
C
D
2
1
Function Position
Raise Insert and secure the pin in hole 1
Lower Insert and secure the pin in hole 2
Fig. 84
A
