Maintenance 7
Position Lubrication point
1
Interval Quantity
1 Boom Daily 2
2
Boom cylinder Daily 2
3
Shovel arm Daily 2
4
Stick cylinder Daily 2
5
Bucket cylinder Daily 2
6
Joint rod Daily 2
7
Easy Lock Daily 2
8
Swiveling console Daily 2
9
Swiveling cylinder 50 o/h 2
10
Teeth of live ring
– see chapter “ Teeth of live ring” on page 7-15
50 o/h 1
11
Live ring (ball bearing)
– see chapter “ Live ring ball bearing” on page 7-14
50 o/h 1
12
Stabilizer blade Daily 4
13
Swiveling dozer blade Daily 7
1. Lubrication on the pins or directly on the cylinders
