7-30 BA E16 en* 1.0 * E16_10_700.fm
7 Maintenance
Fuel filter
The fuel prefilter P and fuel main filter M are located in the engine
compartment.
Both are equipped with a water separator.
Use a suitable container to collect fluids and lubricants as they flow out
and dispose of them in an environmentally friendly manner.
Fig. 279 (symbolic representation)
P
Fig. 280 (symbolic representation)
M
