Maintenance G 2.5A
wc_tx000170gb.fm 28
5.8 Engine Speed
See Graphic: wc_gr000114
Generators require a fixed engine speed to maintain the correct
voltage. Engine speed is controlled by a governor which automatically
adjusts to varying loads on the engine to maintain a constant speed of
3000 rpm. There is no throttle control.
To set the engine to the proper speed:
Turn the speed adjusting screw (a) in or out to obtain a no-load speed
of 3000 rpm.
CAUTION: Setting the engine speed too high or too low may damage
tools and other appliances attached to the generator.
wc_gr000114
a
