Operation PS (3-Phase) Series

wc_tx000123gb.fm 18

Wiring Diagram

Direct-on-line starting

Wiring Diagram

See Graphic: wc_gr000340

If connected to a circuit protected by a fuse, use a time-delay fuse with

this pump.

Ref. Description Ref. Description

1. Coil 2. Circle thermal protector

Wire Colors

B Black R Red Y Yellow Or Orange

G Green T Tan Br Brown Pr Purple

L Blue V Violet Cl Clear Sh Shield

P Pink W White Gr Gray LL Light Blue

G/Y

wc_gr000340

CAUTION
