PT2R OPERATION 1A
1A-5
Engine Make Robin
Engine Model EH17D
Rated Power Hp (kW) 5.0 (3.7)
Spark Plug type NGK - B6HS or Champion L86C
Electrode Gap in. (mm) 0.025 (0.635)
Engine Speed rpm 3600 ± 100
Air Cleaner type Dual element
Engine Lubrication oil grade SAE10W30
service class SF, SE, SD, or SC
Engine Oil Capacity oz. (ml) 21 (650)
Fuel type Regular unleaded gasoline
Fuel Tank Capacity qts. (l) 3.8 (3.6)
1.7 Technical Data
Engine
Weight lbs. (kg) 134 (61)
*Max. Suction Lift ft. (m) 25 (7.5)
Max. Total Head ft. (m) 100 (30)
Mechanical Seal Lubrication oil grade SAE 30
oz. (ml) Approx. 4 (120)
Suction / Discharge Dia. in. (mm) 2 (50)
Maximum Solid Size in. (mm) 1 (25)
Sound Measurements
* Based on pump operating at sea level. Maximum suction lift will be less at higher altitudes.
Pump
The required sound specifications, per Appendix 1, Paragraph 1.7.4.f of the EC-Machine Regulations, are:
- the sound pressure level at operator’s location (L
pA
) = 84 dB(A)
- the sound power level (L
WA
) = 94 dB(A)
These sound values were determined according to ISO 3744 for the sound power level (L
WA
) and ISO 6081 for the
sound pressure level (L
pA
) at the operator’s location.
The sound measurements were obtained with the unit operating on pavement at nominal speed.
