Waeco CF40 - Technical data

EN
CoolFreeze Technical data
41
I
NOTE
If the ambient temperature is above +32°C (+90 °F), the minimum
temperature cannot be attained.
Test/certificates:
The coolant circuit contains R-134a.
CF50 CF60
Connection voltage:
12/24 V
g and 100–240 V ~
Rated current:
– 12 V
g: 7.0 A 7.0 A
– 24 V
g: 3.0 A 3.0 A
– 100–240 V
~ : 1.3 to 0.7 A 1.3 to 0.7 A
Cooling capacity: +10 °C to –18 °C (+50 °F to 0 °F)
Category: 1 1
Energy efficiency class: A+ A+
Energy consumption: 101 kWh/annum 102 kWh/annum
Usable capacity: 47 l 57 l
Climate class: N, ST, T N, ST, T
Ambient temperature: +16°C –
+43 °C
+16°C –
+43 °C
Noise emission: 43 dB(A) 44 dB(A)
Dimensions (W x H x D) in mm: 630 x 480 x 360 630 x 582 x 360
Weight: 18 kg 21.6 kg
