EN
Technical description MCA1215, MCA1225, MCA1235
12
No. in
fig. 1, page 11
Explanation/function
1 Mains connection
2 LIN2 bus connection
3 TENMP/LIN1 bus connection
4 CN2 socket for Alarm and Fan
5 Status LED
6 DIP switch
7 Battery terminals (+)
8 Battery terminals (–)
9 Starter battery connection
No. in
fig. 2, page 12
Explanation/function
1 On/Off switch
2Fan
MCA1215/1225/1235
