SteamForce Pro
Drawing No.
Part No. Description
1
2354056 5m Mains Cable 13A Plug (PS0029)
2354103 5m Mains Cable EUR
2382920 Mains Cable AUS/NZ
2382922 Mains Cable CH
2
2354041 Steamplate Assy Swivel (PS0242)
3
2353950 Small Steam Plate (ST7/b)
4
2370324 Hose Assembly Professional - Polyhose
5
2354058 Elbow (Tank to Hose) (PS0042)
6
2354038 Radiator Cap Plastic Screw (PS0303)
7
2354070 Sight Glass Kit (PS0193)
8
2354073 Tank (PSACC02)
9
2354068 Screw M6 PK 4 (Tank to Frame) (PS0036)
10
2354071 Tank Moulding Cover Black (PS0124)
11
2382315 Element Assy AUS CH 2400W 240V (PS0088)
2354045 Element Assy EU & UK 2750W (PS0404)
12
2354105 Thermal Fuse (PS0402)
13
2354064 Hexagon Lock Nut M6 x 3mm (PS0127)
14
2382383 Cover and Shield
15
2354061 Hexagon Nut M6 x 1.0 (PS0022)
16
2354042 Protective Cap M6 Pk 4 (PS0128)
17
2382385 Cable Assembly for Original Element
18
2354208 Switch Assy 230V (PS0302)
19
2354063 Stand/ Seat Cover (PS0007)
20
2354043 End Caps LMB Pk 2 (PS0332)
21
2354062 Hose Reel (PS0044)
22
2372745 Reel Tube Replacement Kit
23
2382328 Cable Reel (PS0045)
24
2374480 Frame Kit - End Frame RH inc. rubber feet
25
2374479 Frame Kit - End Frame LH inc. rubber feet
26
2374477 Frame Kit - S/plate & x-beam tubes
27
2374478 Frame Kit - Tank Mounting Tubes
28
2374476 Frame Kit - Seat Tubes
29
2354074 Tube Connector (PSACC03)
30
2354054 Securing Screw (PS0006)
Spare Parts (Fig. 2)
