Loosen the pull wire by the adjustment
screw (g. 12, 1). Pull the trigger (g. 12, 2)
disengage the pull wire.
•
Remove the spray head (g. 12, 3) by
pressing the lever (g. 12, 4).
•
Remove the adjustment ring (g. 13, 1)
carefully from the connecting nut (g. 13,
2). Loosen the connecting nut. Remove
the air cap (3), air screen (4), nozzle (5) and
nozzle seal (6) from the spray head.
•
Clean the air cap; air screen, nozzle and
nozzle seal thoroughly.
Attention! Never clean the seals,
nozzle- or air-holes with pointy metal
objects.
•
Remove the suction hose and thoroughly
rinse the suction lter in owing water.
•
If necessary wipe the exterior of the spray
lance.
1
2
3
4
1
2
3
4
5
6
