29. Spare Parts
i
The pictures of spare parts can be found on the page that folds out at the end
of the operating manual.
Spare Parts List: Spray lance (Fig. A1)
Pos. Designation Order No.
1,2 Spray jet adjustment ring, union nut * 2310 811
3,4,5,6 Nozzle set * 2310 810
6 Nozzle seal (2 pcs.) 2304 433
1-7 Complete spray head * 2344 435
8 Spray head cover 2308 176
9 O-ring 2308 158
9,10 Spray lance * 2344 436
Spare Parts List: Perfect Spray spray attachment (Fig. A2)
Pos. Designation Order No.
Perfect Spray spray attachment complete with 800 ml
container
0417 914
1 Union nut 0417 319
2 Air cap 2305 129
3 Nozzle 2305 131
4 Nozzle seal 0417 706
5 O-ring of spray attachment 0417 308
6 Ventilating hose, valve cover, diaphragm 2304 027
7 Suction tube 0417 357
8 Container seal 0417 358
9 Container with cover 800 ml 0413 909
Spare Parts List: Flexio 995 (Fig. A3)
Pos. Designation Order No.
1 Air hose 2308 127
2 Securing clip 2308 123
3 Material hose and control hose * 2314 168
4 Complete suction hose 2308 116
5 Air lter cover 2308 132
6 Air lter (2pcs.) 2310 812
7 Grab handle for Click&Paint spray attachments 0414 240
8 Adapter for Click&Paint grab handle 2344 437
