WAGO 787-1668/0000-0080 User Manual

IO-Link Interface 43
787-1668/0000-0080 Electronic Circuit Breaker
Manual
Version 1.1.0, valid from firmware 2.4.0
The respective commands (see Table “Overview of Acyclic Data”) for adjustable
data are listed below:
Table 28: Status Query (Index 64)
Value
Function
Comment
0
Status query “OFF”
Channel 8 has the functionality of the circuit
breaker.
1
Status query “ON”
Channel 8 has signaling function.
Table 29: Configuration Process data Bytes 3 … 5 (Index 65 … 67)
Value
Function
Comment
1
Switched remote OFF
Switched OFF via interface
2
Switched ON
Switched ON
3
Tripped
Tripped
6
Current > 90 %
Load current > 90% nominal current
14
Current > 100 %
Load current > 100% nominal current
18
Tripped, hardware error
Tripped, hardware error
20
Tripped, thermal release
Tripped, thermal release active
50
Switched OFF local
Local switched off
255
Use process data
Configuration via process data
100
Input voltage
Input voltage (offset: 150)
301
Current Ch 1
Actual current channel 1
302
Current Ch 2
Actual current channel 2
303
Current Ch 3
Actual current channel 3
304
Current Ch 4
Actual current channel 4
305
Current Ch 5
Actual current channel 5
306
Current Ch 6
Actual current channel 6
307
Current Ch 7
Actual current channel 7
308
Current Ch 8
Actual current channel 8
Table 30: Device ID (Index 69)
Value
Function
Comment
47919
787-1668/0000-0080
–
Table 31: Reset Commands for the Trip Counter (Index 71)
Value
Function
Comment
1 … 8
Reset
Counter channel 1 … 8 reset
Table 32: Configuration Commands for Trip Current (Index 310 … 317)
Value
Function
Comment
1000
1
Trip current 1 A
2000
2
Trip current 2 A
3000
3
Trip current 3 A
4000
4
Trip current 4 A
6000
6
Trip current 6 A
8000
8
Trip current 8 A
10000
10
Trip current 10 A
