Snap Shot / Snap Shot
Press EDIT button to enter keyboard multi-function
mode, and then press SNAP SHORT, DATA +/-,
SLIDER, WHEEL, PEDAL, R1~R4 and R5~R8 and etc all
together to transmit those data at one time.
Pressione o botão EDIT para entrar o modo multifunção
do teclado e então pressione SNAP SHOT, DATA +/-,
SLIDER, WHEEL, PEDAL, R1~R4 e R5~R8 e etc., todos
juntos para transmitir aqueles dados de uma única vez.
Upload and Download
Use USB port to connect with computer can upload or download user parameters: to upload Krypton25/49/61
panel parameters to computer, or, to download the parameters from computer to Krypton25/49/61.
The transmit messages are system exclusive messages in form of F0......F7. According to different sequencer
software, there are different ways to receive/send system message: mainly record/playback style and system
message window style. Details are as follows.
• Record Style. E.g. Cubase
>> From Krypton25/49/61to computer (UPLOAD)
1. Use USB cable to connect computer and Krypton25/49/61;
2. Set Krypton25/49/61 parameters;
3. Open a new MIDI project in Cubase;
4. Select Krypton25/49/61 as MIDI input and neglect output;
5. Uncheck the box – SYSEX in RECORD to validate system message. (FILE-> PREFERENCES-> MIDI-> MIDI FILTER);
6. Cubase starts to record;
7. Press EDIT button to enter keyboard multi-function mode, and then press UPLOAD, Krypton25/49/61 enters into
system message upload mode. LED displays SEu. After upload completes, LED displays don.
8. Cubase stops recording.
9. In Cubase, select MIDI->OPEN LIST EDITOR to find received system message; press COMMENT to open system
message window and use EXPORT to save the message in *.SYS format.
>> From computer to Krypton25/49/61 (DOWNLOAD)
1. Use USB cable to connect computer and Krypton25/49/61;
2. Open a new MIDI project in Cubase;
3. Select Krypton25/49/61 as MIDI output;
4. Export saved system message file (*.SYS) into Cubase.
5. Press EDIT button to enter keyboard multi-function mode, and then press DOWNLOAD, Krypton25/49/61 enters
into system message download mode. LED displays SEd.
6. Cubase starts to playback and transmit system message to Krypton25/49/61;
7. LED displays don after Krypton25/49/61 finishes receiving correct system message. 8. System starts SNAP SHOT
function to transmit download setting message to sequent device.
• System Message Window Style. E.g. Cakewalk
Operate Krypton25/49/61 in the same way as under Record Style, only different operation
in sequencer software.
>> From Krypton25/49/61 to computer (UPLOAD)
1. Use USB cable to connect computer and Krypton25/49/61;
2. Set Krypton25/49/61 parameters;
3. Open a new MIDI project in Cakewalk;
4. Select Krypton25/49/61 as MIDI input and neglect output;
5. Open system message window: VIEW->SYSX; select a BANK and ↓ ; select YOU START DUMP ON INSTRUMENT
and then Cakewalk enters into system message receive mode.
6. Press EDIT button to enter keyboard multi-function mode, and then press UPLOAD, Krypton25/49/61 enters into
system message upload mode. LED displays SEu. After upload completes, LED displays don.
7. Use SAVE in Cakewalk to save received message in *.SYS format.
>> From computer to Krypton25/49/61 (DOWNLOAD)
1. Use USB cable to connect computer and Krypton25/49/61;
2. Open a new MIDI project in Cakewalk;
3. Select Krypton25/49/61 as MIDI output;
4. Open system message window: VIEW->SYSX; select a BANK and import saved system message file.
5. Press EDIT button to enter keyboard multi-function mode, and then press DOWNLOAD, Krypton25/49/61 enters
into system message download mode. LED displays SEd.
6. Use Cakewalk system message send function to send system message to Krypton25/49/61;
7. LED displays don after Krypton25/49/61 finishes receiving correct system message. 8. System starts SNAP SHOT
function to transmit download setting message to sequent device.
