Waldorf IN8200E INL8200E INB8200E INLB8200E IN8400E INL8400E INB8400E INLB8400E Installation And Operating Manual

6
This model is delivered completely assembled. Ensure that the adjustable feet are securely attached.
NOTE:
 This appliance is fitted with adjustable feet to enable the appliance to be positioned
securely and level. This should be carried out on completion of the electrical
connection. Refer to the ‘Electrical Connection’ section below.
NOTE: ALL ELECTRICAL CONNECTIONS MUST ONLY BE CARRIED OUT BY A QUALIFIED
PERSON.
Each pasta cooker should be connected to an adequately protected power supply and isolation switch
mounted adjacent to, but not behind the pasta cooker. This switch must be clearly marked and readily
accessible in case of fire.
1. Check that the electricity supply is correct as shown on the Rating Plate attached to the inside of the
access door.
2. The supply terminal connections are located at the lower front of the pasta cooker.
3. Open the door and remove the service panel (4 screws) located below the control panel, to allow
connection access for the electrical supply.
4. Bring the supply cable up through the grommet at the back of the pasta cooker, and through the
compression type gland provided on the rear of the main electrical switchgear panel.
5. Connect the mains supply to L1, L2 and L3 switch connections for 3 phases.
6. Connect neutral and earth conductors to the appropriately marked terminals on the terminal block.
7. For all connections ensure that conductors are secure and appropriately terminated.
8. Tighten the cable gland to secure against tension on the cable.
NOTE:
 This appliance must be grounded / earthed.
 Fixed wiring installations must incorporate an all-pole disconnection switch.
NOTE: The water connection shall be installed in accordance with local water regulations in force
and the applicable standard / code, e.g. EN 1717 in UK / Ireland, PCA in Australia.
A cold water supply must be connected to the water inlet connection (R
1
/
2
" BSP), located 49mm from
the LH side, 556mm from rear and 139mm from the floor.
The water inlet pressure must be as follows:-
Minimum water supply pressure 150 kPa (22 psi).
Maximum water supply pressure 550 kPa (80 psi).
