WX530
Trailer Wood Splitter
Service and Maintenance
33
Fig. 30 – Grease Points
00662
1
2
2
7.4 Grease Points
Use a hand-held grease gun for all greasing. Pump one shot
of grease per fitting.
Look for this decal on your machine. It
indicates a grease point and the interval in
hours.
• Wipe grease fitting with a clean cloth before greasing to
avoid injecting dirt and grit.
• If fittings do not take grease, remove and clean them
thoroughly. Replace grease fittings as necessary.
Location
Every 40 hours of operation
or as required
1 Frame slide
Location
Every 100 hours of operation
or annually
2 Axle bearings – 2 places
