Walmart GFM00752C - Page 7

Step 3: Attach the post (I) to the back connector bar (A) and outer bars (D) on the pre-assembled
parts with the M6x80 bolt & washer (DD) and M6x15 bolt & washer (AA) Repeat to attach the
.
Stock# BH17-092-099-59 / GFM00752C
Walmart Assembly Instruction
BHG 9*8.6FT Pergola
Cut the rope in the wheel on the outer bars (D) and center bar (E).
posts (I) to the front connector bar (B) and outer bars (D). Tighten all bolts with Allen wrench (FF).
