WAM R03 Series User Manual

04.12
3
VAL.120.--.R.4L
-
-
-
-
VCP
Series R03
VCP_ _ _C
VCP VALVES COMPONENTS LIST - LISTE DER VENTILKOMPONENTEN- LISTE COMPOSANTS SOUPAPE VCP - ELENCO COMPONENTI VALVOLE VCP
02
POS. QUANT. DESCRIPTION BESCHREIBUNG
NORME
NORMEN
1 1 UPPER EDGED STUB PIPE VCP OBERER STUTZEN VCP
2 3 EYEBOLT RINGSCHRAUBE UNI2948 3 1 LOWER EDGED STUB PIPE VCP UNTERER STUTZEN VCP
4 23 NORMAL HEX NUT NORMALE SK-MUTTER UNI5588
5 3 THREADED TIE-ROD GEWINDE-ZUGSTANGE 6 25 AISI304WASHER UNTERLEGSCHEIBEEDELSTAHL1.4301 UNI6592 7 1 VCP273VALVESEALINGDISK+GASKET DICHTSCHEIBE BENTIL VCP + DICHTUNG 8 8 GUIDE WASHER FÜHRUNGSSCHEIBE
9 3 COMPRESSION PSRING FOR OVERPRESSURE GEGENDRUCKFEDER FÜR ÜBERDRUCK
10 4 SAFETY BELLOWS SCHUTZBALG
11 10 UNI6593SUPPORTINGWASHER AUFLEGSCHEIBEUNI6593 UNI6593
12 7 WASHER MADE OF BLACK RUBBERIZED CANVAS GUMMITUCHSCHEIBE 13 1 GASKET FOR EDGED STUB PIPE VCP DICHTUNG FÜR STUTZEN VCP
14 1 VCP DISC NEGATIVE PRESSURE SCHEIBE FÜR VCP UNTERDRUCK
15 1 HEX HEAD SCREW SK-SCHRAUBE ISO4016
16 1 COMPRESSION SPRING FOR NEGATIVE PRESSURE GEGENDRUCKFEDER FÜR UNTERDRUCK
17 1 VCP CAP KAPPE VCP
18 9 UNI1751WASHER FEDERSCHEIBEUNI1751 UNI1751-A
19 9 AISI304HEXHEADSCREW SK-SCHRAUBEEDELSTAHL1.4301 ISO4018
POS. QUANT. DESCRIPTION DESCRIZIONE
NORMES
NORME
1 1 TRONÇON SUPERIEUR VCP TRONCHETTO BORDATO SUPERIORE VCP
2 3 ANNEAU GOLFARE UNI2948 3 1 TRONÇON INFERIEUR VCP TRONCHETTO BORDATO INFERIORE VCP
4 23 ECROU HEXAGONAL NORMAL DADO ESAGONALE NORMALE UNI5588
5 3 TIRANT FILETÉ TIRANTE FILETTATO 6 25 RONDELLEENAISI304 RONDELLAINAISI304 UNI6592 7 1 DISQUED'ETANCHEITESOUPAPEVCP+JOINT DISCO DI TENUTA VALVOLA VCP + GUARNIZIONE
8 8 RONDELLE DE GUIDAGE RONDELLA DI GUIDA
9 3 RESSORT DE COMPRESSION POUR SURPRESSION MOLLA A COMPRESSIONE PER SOVRAPRESSIONE
10 4 SOUFFLET DE PROTECTION SOFFIETTO DI PROTEZIONE
11 10 RONDELLED'APPUIUNI6593 RONDELLADIAPPOGGIOUNI6593 UNI6593
12 7 RONDELLE EN CAOUTCHOUC TOILÉ ROSETTA IN GOMMATELA
13 1 JOINTPOURTRONÇONSVCP GUARNIZIONE PER TRONCHETTI BORDATI VCP
14 1 DISQUE POUR VCP DEPRESSION DISCO PER VCP DEPRESSIONE
15 1 VIS A TETE HEXAGONALE VITE A TESTA ESAGONALE ISO4016
16 1 RESSORT DE COMPRESSION POUR DEPRESSION MOLLA A COMPRESSIONE PER DEPRESSIONE
17 1 COUVERCLE VCP CAPPELLO VCP
18 9 RONDELLEELASTIQUEGROWERUNI1751 ROSETTAELASTICAGROWERUNI1751 UNI1751-A
19 9 VIS A TETE HEXAGONALE VITE A TESTA ESAGONALE ISO4018
kit
kit
A A
VALVE COMPONENTS
VENTILKOMPONENTEN
COMPOSANTS SOUPAPE
COMPONENTI VALVOLA
DADO CIECO
CAP NUT
HUTMUTTER
ÉCROUT BORGNE
