2 D10-991-2400 5/1/04
Max Pressure Metallic: 1000 psi (70 bar)
Non-Metallic: 250 psi (17 bar)
Slurry Duty (SD): 300 psi (21 bar)
Capacity @ Max Pressure
rpm gpm I/min
D/G-10-X 1450 7.8 29.0
D/G-10-E 1750 8.0 30.3
D/G-10-S 1750 6.0 22.7
D/G-10-I 1750 3.9 14.9
Delivery @ Max Pressure
revs/gal revs/liter
D/G-10-X 185 50
D/G-10-E 219 58
D/G-10-S 292 77
D/G-10-I 448 117
Max Inlet Pressure
Metallic: 250 psi (17 bar)
Non-Metallic: 50 psi (3.5 bar)
Slurry Duty (SD): 50 psi (3.5 bar)
Max Temperature
Metallic: 250°F (121°C) – consult factory for
temperatures above 160°F (71°C)
Non-Metallic: Polypropylene: 120°F (49°C);
Kynar, Celcon & Slurry Duty: 140°F (60°C)
– consult factory for temperatures
above 120°F (49°C)
Inlet Port D-10: 1 inch NPT
G-10: 1 inch BSPT
Discharge Port D-10: 3/4 inch NPT
G-10: 3/4 inch BSPT
Shaft Diameter 7/8 inch (22.22 mm)
Shaft Rotation Bi-directional
Bearings Tapered roller
Oil Capacity 1.1 US quarts (1.05 liters)
Weight Metallic Heads: 48 lbs (22 kg)
Non-Metallic Heads: 35 lbs (16 kg)
Calculating Required
Horsepower (kW)*
+
15 x rpm
63,000
gpm x psi
1,460
=
electric motor HP*
D/G-10 Specifications
+
15 x rpm
84,428
lpm x bar
511
=
electric motor kW*
* rpm equals pump shaft rpm. HP/kW is required application
power. Use caution when sizing motors with variable speed
drives.
D/G-10 Contents
Page
Specifications......................................................................... 2
Dimensions ............................................................................ 4
Installation.............................................................................. 5
Maintenance .......................................................................... 9
Service (Fluid End) .............................................................. 10
Service (Hydraulic End)....................................................... 15
Troubleshooting ................................................................... 18
