Wanner Engineering Hydra-Cell G-25 - Page 26

6
WANNER ENGINEERING, INC.
1204 Chestnut Avenue, Minneapolis, MN 55403
TEL: (612) 332-5681 FAX: (612) 332- 6937
TOLL-FREE FAX [US only]: (800) 332-6812
www.hydra-cell.com
email: sales@wannereng.com
H-25 Series Replacement Parts Kits
(with metallic pump head)
1-3 Pump Configuration
D25 For all H-25 Pumps
4 Kit Designator
K Complete Fluid End Kit
D Diaphragm Kit
V Valve Kit (diaphragm not included)
5-6 Pump Head Version
52 Metallic Pump Head Version
7 Diaphragm & O-ring Material
E EPDM
G Viton-XT
J Teflon
®
P Neoprene
T Buna-N-XS
8 Valve Seat Material
C Ceramic
D Tungsten Carbide
H 17-4 PH Stainless Steel
N Nitronic 50
T Hastelloy
®
C
X Not included in Diaphragm Kit
9 Valve Material
C Ceramic
D Tungsten Carbide
F 17-7 PH Stainless Steel – Machined
H 17-7 PH Stainless Steel – Stamped
N Nitronic 50
T Hastelloy
®
C
X Not included in Diaphragm Kit
10 Valve Springs
E Elgiloy
®
H 17-7 PH Stainless Steel
T Hastelloy
®
C
X Not included in Diaphragm Kit
11 Valve Spring Retainers
C Celcon
H 17-7 PH Stainless Steel
M Kynar
®
P Polypropylene
T Hastelloy
®
C
Y Nylon (Zytel)
X Not included in Diaphragm Kit
6 9 10
11
53
2
1
84
ORDERING INFORMATION: A Replacement Parts Kit contains 11 digits corresponding to customer-specified design options.
7
Order
Digit Code Description
Kit Designator
Part Number* Description Qty K D V
D25-018- ___ Diaphragm 3 • •
D25-047- ___ O-ring, follower 3 • •
D25-074- ___ O-ring, outlet valve 3 • • •
D25-097- ___ O-ring, outer manifold 1 • • •
D25-073- ___ O-ring, inner manifold 1 • • •
D10-083- ___ O-ring, center manifold
1
1 • • •
D25-083- ___ O-ring, center bolt
2
1 • • •
D25-035- ___ O-ring, valve seat 6 • •
D25-020- ___ Valve seat 6 • •
D25-021- ___ Valve 6 • •
D25-022- ___ Valve spring 6 • •
D25-092- ___ Tetra seal
3
6 • •
D25-023- ___ Retainer, valve spring 6 • •
A01-113-3400 Threadlocker 1 • •
Kit Contents
* Last four digits of part numbers with –___ refer to specic material of construction.
1
D10-083 is for brass head only.
2
D25-083 is for heads other than brass.
3
Not included with metal spring retainers.
© 2004 Wanner Engineering, Inc. Printed in USA
H25-991-2402B 5/2004, Revised 11/2006
