17
Wap 2200 W Wap 2200 Wap 3300
Wap 2200 ST Wap 3300 ST
Working pressure bar 130-10 195-20 220-20
110-10 (GB)
Volume flow l/h 600-250 900-250 1100-250
Voltage 230 V 1~ EU, ZA - -
Voltage 220 V 1~ EXP - -
Voltage 230/240 V 1~ GB, AU - -
Voltage 200 V 3-phase AC - JP JP
Voltage 220 V 3-phase AC - KR KR
Voltage 230 V 3-phase AC - BE -
Voltage 380 V 3-phase AC - EXP, BR EXP
Voltage 400 V 3-phase AC - EU,FR EU, FR
Voltage 400-415 V 3-phase AC - AU -
Frequency Hz 50 50 (60 JP) 50 (60 JP)
Connected electric load kW 3.6 6.7 8.8
2.9 (GB)
Max. inlet temperature 60°C (50°C in suction mode)
Max. water supply pressure bar 10 10 10
Dimensions LxWxH 650 x 402 x 885
Weight of cleaner
(Weight of spraying device) kg 42 (5) 43 (5) 47 (5)
Sound pressure level measured
1 m from the cleaner in
accordance with DIN 45635 dB(A) 68.6 80.4 81.6
Oil fill capacity l 0.35 0.35 0.35
Cleaning agent tank capacity l 10 10 10
Recoil forces N 27 49 64
Please note the specifications given on the rating plate!
SPECIFICATIONS
