Waring BOLT WSB38X - Product Parts Identification; Component Overview

5
PARTS
1. Battery Pack
1a. Battery Clips
2. Battery
Quick-Charge Station
3. Charge Indicator Light –
Solid Green = Fully Charged
Blinking Green = 70-90% Charged
Blinking Orange = 50-70% Charged
Blinking Red = Low Voltage,
Under 50% Charged
4. Adapter
5. Motor Housing
6. Safety Button
7. Power Button
8. Speed Control (+ and -)
9. Speed Indicator Lights – blue
(also shows charge level in red)
❑ ❑ ❑ ❑ ■
❑ ❑ ❑ ■ ■
❑ ❑ ■ ■ ■
❑ ■ ■ ■ ■
■ ■ ■ ■ ■
1 2 3 4 5
10. Stainless Steel Shaft
11. Protective Blade Guard
12. Metal Blade
13. Storage/Transport Bag
7
8
9
10
11
12
13
2
4
5
3
1
6
(on the
back)
1a
