IMPORTANT UNPACKING INSTRUCTIONS
Remove your new Waring Pro
®
Juice Extractor from the
box. With the unit facing you, unlock cover by turning
cover clockwise.
• Remove cover and take out any packaging material
used to protect the shredder disc (Part #3).
• Lift and remove strainer basket (Part #3).
• Unlock and remove pulp collector (Part #4) by turning it
clockwise, then remove.
ASSEMBLY
• Fit the pulp collector bowl (4) on top of the motor
housing (5) and lock into place.
• Place strainer basket with shredder disk (3) inside pulp
collector (4) over drive coupling.
• Place cover and feed tube (2) over pulp collector bowl
(4) with the nose just left of the juice spout.
• Lock cover and feed tube (2) by twisting
counterclockwise until it snaps shut and the nose lines up
with the juice spout.
PARTS
1. Pusher
2. Feed tube and cover
3. Strainer basket with
shredder disk
4. Pulp collector with juice spout
5. Motor housing
6. Power switch
7. 32 oz. Stainless steel
juice collector cup
8. Cleaning brush for
strainer basket
3
7.
6.
5.
1.
2.
3.
4.
8.
