7
1. Attach grinder/feeder head to
motor housing.
2. Insert feed screw into the
grinder/feeder head.
3. Assemble cutting blade on
the end of the feed screw.
4. Place the coarse cutting plate
in the grinder/feeder head.
5. Put the desired sausage
attachment (small or large)
into the screwing ring and
screw onto the grinder/feeder
head.
6. Slide casing over the end of the
sausage attachment, leaving
approximately 2" overhanging the
end of the sausage attachment.
Grinder/feeder head
Motor housing
Feed screw
Grinder/feeder head
Cutting blade
Coarse cutting
plate
Grinder/feeder head
Grinder/feeder head
Sausage attachment
Screwing ring
Pusher
Die-cast
hopper
Sausage
attachment
Casing
ASSEMBLING THE WARING PRO
®
MEAT GRINDER TO MAKE SAUSAGES
