WarmlyYours Infinity - Electrical Considerations

12
Electrical Considerations
Diagram F: Wiring Diagram (hardwired models only)
ENSURE THE SYSTEM IS GROUNDED
WIRING DIAGRAM
FOR TOWEL WARMERS
WITH HARDWIRED TIMERS OR SWITCHES
(GK16-30090-0001, GK16-30090-0003, GK16-30090-0002)
NEUTRAL (WHITE)
NEUTRAL (WHITE)
CONNECT TO HOUSE GROUND
CONNECT
TO HOUSE
GROUND
HOT (BLACK)
3-WAY TERMINAL*
(YELLOW/RED)
LOAD (RED)
* - WE RECOMMEND TO ISOLATE THE YELLOW
3-WAY WIRE FROM THE OTHER WIRES USING A
SOLDERLESS WIRE-NUT CONNECTOR.
BLACK OR BLUE
(HOT)
WHITE OR BROWN
(NEUTRAL)
GREEN/YELLOW
(GROUND)
2” x 4” ELECTRICAL
BOX FOR CONTROL
HOUSE
BREAKER BOX
2” x 4” ELECTRICAL BOX
HOT LOAD
(BLACK OR BLUE)
LINE (BLACK)
NEUTRAL (WHITE)
LOAD (RED)
GROUND (GREEN)
120VAC HOT
NEUTRAL
CONTROLLER
IS OPTIONAL
(SOLD SEPARATELY)
GROUND
GROUND
(GREEN/YELLOW)
NEUTRAL LOAD
(WHITE OR BROWN)
TOWEL
WARMER
TOWEL
WARMER
ELECTRICAL ROUGH-IN
3-WAY WIRE
(YELLOW/
RED)
GROUND
(GREEN)
POWER
SOURCE
120VAC
