WARN INDUSTRIES PAGE 2 70557A2
I. TABLE OF CONTENTS
Parts List page 2
Tools Required page 2
Installation page 3-5
Winch and Lowering Plow Instructions page 6-7
Maintenance/Care page 8
II. PARTS LIST
Part Number Qty Description
A1 1 Plow Mount
B1 4 5/16-18 x 1 3/8” x 2” u-bolt
B2 8 5/16” Flat Washer
B3 8 5/16-18 Lock Nut
Caution
MoMo
MoMo
Mo
ving Pving P
ving Pving P
ving P
arar
arar
ar
ts Entanglement Hazardts Entanglement Hazard
ts Entanglement Hazardts Entanglement Hazard
ts Entanglement Hazard
FF
FF
F
ailure tailure t
ailure tailure t
ailure t
o obsero obser
o obsero obser
o obser
vv
vv
v
e these instructions could lead te these instructions could lead t
e these instructions could lead te these instructions could lead t
e these instructions could lead t
o minor or moderato minor or moderat
o minor or moderato minor or moderat
o minor or moderat
e injure injur
e injure injur
e injur
yy
yy
y
..
..
.
Always take time to fully read and understand the installation and Operations Guide included with this product.
Never operate this product if you are under 16 years of age.
Never operate this product when under the influence of drugs, alcohol or medications.
Read installation and operating instructions thoroughly.
Notice
Equipment Damage
Always refer to the Installation and Specification Guide, supplied in the winch kit, for all wiring schematics and specific details
on how to wire this WARN product to your vehicle.
Never overtighten the j-bolt to the bracket. Doing so will pinch the winch cable against the bracket, damaging the cable.
Always put the end of the actuator cable through the slot in the Termination Bracket. Terminating the cable through any other
hole in the bracket will cause the bracket to not function properly and will drastically reduce the life of the actuator cable.
Read installation and operating instructions thoroughly.
III. TOOLS REQUIRED
- Ratchet
- 10mm Socket
- 1/2” Socket
- 3/8” Drill
Note:
Please refer to the Winch and Lowering Plow Instructions, p 5-6, if you plan to lower your plow using a
winch.
B1
A1
B3
B2
To Next Page
