Hardware Identifier
Description Qty Purpose
H1. 5/16” x 1 ¾” 12 (8) Step 2 side panels, (4) Step 7 corner blocks
H2. 5/16” x 1 3/8” 6 Step 7 Playfield/Table Top
H3. 1/4" x 1 ½” 2 Step 5 Ball Catch
H4. 1/4" x 1 ¾” 4 Step 9 Top Plate
H5. 3/16” x 1 ½” 4 Step 10 Score Beads
H6. 1/4" x 1 ¼” 4 Step 3 Goal Boxes
H7. 1/4" x 1 ¾” 4 Page 5 Installation of Light Brackets
