Warwick Basses - Buzzard JE Signature; Corvette; Corvette $$ NT; Corvette Std. Active

10
Buzzard JE Signature
Active pickups / 2-band active electronics
* Pulling on the volume knob bypasses the onboard active preamp and deactivates the tone controls
** The top knob boosts or cuts the treble and the bottom knob boosts or cuts the bass.
Corvette $$ / Cor vette $$ NT / Streamer $$
Passive pickups / 2-band active electronics
* Pulling on the volume knob bypasses the onboard active preamp and deactivates the tone controls
** When the switch is in the up position the neck (N) and bridge (B) pickups work as humbuckers and are wired in series.
When the switch is in the middle position the neck (N) and bridge (B) pickups work as single coils. When the switch is in
the down position the neck (N) and bridge (B) pickups work as humbuckers and are wired in parallel.
Corvette Std. active / Corvette Taranis active
Pickups active / 2-band active electronics or pickups passive / 2-band active electronics
* Pulling on the volume knob bypasses the onboard active preamp and deactivates the tone controls
** The top knob boosts or cuts the treble and the bottom knob boosts or cuts the bass.
Push/Pull
Volume Control
Pickup
Balance Control
Stacked Bass/Treble
Tone Control
Bridge
**N
**B
Push/Pull
Volume Control
Pickup
Balance Control
Treble
Tone Control
Bridge
Bass
Tone control
**
*
*
Push/Pull
Volume Control
Pickup
Balance Control
Stacked Bass/Treble
Tone Control
Bridge
**
*
