Warwick Gnome i Pro V2 User Manual

Warwick Amplification Gnome Series - Bass Amplifier Heads
Gnome · Gnome i · Gnome i Pro V2 · Gnome i Pro 600
Risk of Electric Shock
To reduce the risk of re or electric shock, do not remove the screws or open the unit. The Warwick Gnome has no user-serviceable parts inside.
Only allow qualied service personnel to service. Do not expose the units to rain or moisture.
FCC Certication
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference received, including interference that may cause undesired operation.
Volume Warning
This amplier is capable of producing high sound pressure levels. Continued exposure to these high sound pressure levels can cause permanent
and irreversible hearing damage. Ear protection is recommended if the unit is operated at high volume for long period of time. If you experience
any hearing loss or ringing in the ears you should consult a doctor.
Main Features
• Ultra-portable, lightweight bass amplier head
• Solid-state design, class D amplier circuitry
• Power:
200 W at 4 ohms / 130 W at 8 ohms (Gnome and Gnome i)
280 W at 4 ohms / 180 W at 8 ohms (Gnome i Pro V2)
600 W at 4 ohms / 350 W at 8 ohms (Gnome i Pro 600)
• 3-band EQ with +/- 15 dB cut/boost
• 6.35 mm (
1
/
4
") headphone output for silent practice
• 3.5 mm (
1
/
8
") AUX input to connect external sound sources (Gnome i Pro V2)
• Post-EQ balanced XLR DI output with switchable ground lift
• More than 10 MOhms input impedance provide maximum sensitivity for passive pickups
• USB audio interface on the Gnome i and Gnome i Pro V2 models:
· For PC, MAC or compatible mobile devices
· Direct recording via DAW plug-ins
· No drivers or special software required
• Dimensions (L x W x H):
170 x 118 x 45.5 mm / 6
11
/
16
" x 4
41
/
64
" x 1
51
/
64
" (Gnome and Gnome i)
200 x 137 x 49 mm / 7
7
/
8
" x 5
25
/
64
" x 1
59
/
64
" (Gnome i Pro V2)
340 x 250 x 100 mm / 13
25
/
64
" x 9
27
/
32
" x 3
15
/
16
" (Gnome i Pro 600)
• Weight:
0.96 kg / 2.12 lbs (Gnome) / 0.98 kg / 2.16 lbs (Gnome i) / 1.35 kg / 2.98 lbs (Gnome i Pro V2) / 3.01 kg / 6.62 lbs (Gnome i Pro 600)
Introduction
Thank you for purchasing a Warwick Gnome amplier - clear, dened bass sound, true power and a built-in USB audio interface on the Gnome i
and Gnome i Pro V2 models - all packed in a super compact, lightweight design that will easily t in your pocket! The Gnome amp heads were de-
veloped to oer transparent, crisp and noise-free performance combined with an ultra-portable, lightweight design in an aordable and reliable
amp for discerning musicians and for the seasoned professionals.
The Warwick Gnome i and Gnome i Pro V2 oer an easy-to-use audio interface without any special driver or software requirements. The USB
audio interface allows you to connect your Gnome amp to a PC, MAC or compatible mobile device to record your playing or to process your signal
using digital audio software plug-ins.
Precautions / Safety Instructions
Power Supply
The Warwick Gnome is powered by an IEC power cable, which provides AC power to the unit. Connect the IEC power cable to provide power.
Improper line voltage can cause serious damage to the unit, always check the line voltage marking on the amplier before you connect the IEC
power cable. Unplug the unit when not in use or during electrical storms.
Connections
Always turn o power to all other equipment before connecting or disconnecting. This will help to prevent malfunction and damage to any of the
devices used.
Cleaning
Clean only with a soft, dry cloth.
Handling
Do not apply excessive force to the switches or controls. Do not block any ventilation openings. Install in accordance to the instructions. Do not let
paper, metal, dirt or other objects come into contact with the device or its connections. Take care not to drop the device and do not subject it to
shock or excessive pressure. The unit should be connected to a mains socket outlet with a protective earthing connection. Replace fuse with rated
value, never bridge defective fuses. Before changing fuse disconnect power cable from unit! To avoid deformation, discoloration, or other serious
damage, do not expose this unit to any of the following conditions:
• Direct sunlight
• Strong magnetic elds
• Excessively dusty or dirty environments
• Strong vibration or shock
• Heat sources
• Extreme temperature
• High humidity or moisture
