WASD V3 - Macro Programming; Macro Recording Process; Moving Pgm or Fn Keys; Macro Programming Limitations

Macro Programming
Action
LED State
LED1 = Caps Lock, LED2 = Scroll Lock
1. Enable Pgm Key and Fn Key
LED1+2 = Normal function
2. Press Pgm + Fn to enter Macro Programming
LED1 = Green
3. Press target key or key combo
LED1 = Red
4. Input Programming
LED2 = Flash red on input
5. Press Pgm to save macro
LED1+2 = Flash green 2 times
6. Go back to Step 3 or press Pgm + Fn to exit
Macro Programming
LED1+2= back to normal function
Moving Fn, Pgm, Layer Swap (M or < or >or ?), or Backlight Control (F10, F11, F12) key positions
1. Enable Pgm Key and Fn Keys
LED1+2 = Normal function
2. Press Pgm + Fn to enter relocation Programming
LED1 = Green
3. Press and hold Pgm or Fn, or Layer Swap, or
Backlight Function key for 5 seconds
LED1 = Red
LED2 = Flash red, then solid green after 5
seconds
4. Input destination key
LED1 = Solid green
LED2 = Flash Green
5. Go back to Step 3 to move another or press Pgm
+ Fn to exit relocation Programming
LED1+2= back to normal function
Macro Programming Limitations
1. Each layer can record up to 64 macros
2. Each macro can hold up to 32 keys (not including delay functions)
3. Target can be single key or a combo using Fn key up to 3 keys
(ie: “W”, “Fn + W”, “Fn + Ctrl + W”)
4. When moving Fn, Pgm, Layer swap, or backlighting control keys; if the key
position is already populated with a function it will not allow you to
overwrite, you must move the underlying function first.
Clear Macro Programming for Layer
Press and hold the Fn key, left shift and the target layer key for 2 seconds.
LED’s will flash blue 5 times indicating that layer has been reset. (For example,
hold Fn + left shift + m to reset Layer 1)
