UD Operating Instructions
START
• Turn on at wall
• Ensure the Scrap tray (3) is in place
• Ensure the Upstand (1) and Drain filter (2) is in place and shut door
• Press Power button for 3 seconds to turn machine on and begin the fill cycle
OPERATION
• Select cycle using Up/Down buttons (use the Heavy cycle whenever possible)
• Press Start button (once this is Green or Orange) to begin washing
• Timer counts down to 00 then resets after door is opened
START BUTTON COLOURS
White = machine is filling Purple = door is open
Red = cycle is running Orange = machine is heating
Green = rinse water is up to temperature Blue = power saving mode
NOTE: The machine may be started while Orange light is on and while rinse water is being
heated and the timer will pause at 22 seconds until rinse water is up to 83 degrees
SHUT DOWN – EVERY NIGHT
• Select Drain cycle via Up or Down buttons
• Remove drain Upstand (2) and shut door
• When Drain cycle is finished after 100 seconds, remove and rinse Upstand (1), Drain filter
(2) and Scrap tray (3) before replacing back in machine along with Upstand (2)
CLEANING – AT LEAST ONCE A WEEK
• Remove, rinse and replace:
• Upstand 1
• Drain Filter 2
• Scrap Tray 3
• Thumbscrew 4
• Wash Arm 5
• Rinse arm 6
• Inspect and clear all jets in the wash and rinse arms
SUGGESTED BEST PRACTICE
• Pre-rinse Scrape and/or rinse plates and glasses in cool water
• Chemical Use good quality non foaming commercial detergent and drying agent
Do not use domestic detergent which will cause the machine to foam
START
UP
POWER
DOWN
6 UD - Operator Manual 170323
