6. Attach the doorbell onto the Horizontal Angle
Mount.
7. Choose your desired angle and tighten the tiny
screws on the top and bottom of the mount.
If your doorbell is hardwired: Connect the wires
to the doorbell as shown.
Installation with the Existing Nest Doorbell's
Wedge.
To install the Horizontal Angle Mount onto your
existing doorbell’s wedge, you can follow all the
steps 2 - 7 as above.
The only changes needed are:
- Ignore Step 1.
- For Step 3, instead of mounting the Horizontal
Angle Mount to the wall, you will need to mount
it and attach it to the doorbell’s wedge.
Get More Support
Scan the QR code below or, email us
at contact@wasserstein-home.com
