English
CONFIGURE THE AP DEVICE WITH WATCHGUARD WI-FI CLOUD
Connect the AP device
• Connect an Ethernet cable between your network and the
Ethernet (LAN) interface on your AP device.
• You must enable DHCP on the network where you connect the AP device.
- Make sure that the AP device has Internet connectivity and can communicate to WatchGuard
Wi-Fi Cloud services on these ports: HTTP TCP 80/443; UDP 123 (NTP); and UDP 3851.
If you have a Firebox the WatchGuard Wi-Fi Cloud policy opens the necessary ports.
• Connect the optional power adapter or PoE injector (sold separately).
• After you power on the AP device, wait a few minutes until the Power indicator turns o and the
Ethernet (LAN) indicator turns solid green. This shows the AP device is online and can communi-
cate with the WatchGuard Wi-Fi Cloud.
Connect to the WatchGuard Wi-Fi Cloud
To connect to the WatchGuard Wi-Fi Cloud, log in to the WatchGuard Support Center or go to
https://login.watchguard.cloudwi.com
Congure your AP device
1. From the WatchGuard Wi-Fi Cloud Dashboard, launch Go.
2. Add a new wireless network and type the SSID you want to use.
3. Select a security mode. We recommend WPA2 PSK.
4. Click Save to reset your AP device with the new conguration.
5. Toggle on your new wireless network.
The WatchGuard Wi-Fi Cloud automatically sets up your SSID Prole, creates a new Device Template and
applies the template to your device at the top-level location. From the Wi-Fi Cloud Dashboard tab in your
browser, select Manage to view and rene your conguration.
Upgrade your AP Device
We recommend you upgrade your AP device to make sure it uses the most current rmware.
See Help for complete instructions.
For complete information about how to congure your AP device with WatchGuard Wi-Fi Cloud,
see WatchGuard Wi-Fi Cloud Help at http://wgrd.tech/wi-cloud-help
CONFIGURE THE AP DEVICE ON THE FIREBOX
Connect the AP device
• Connect the AP device to a Firebox trusted or optional interface with DHCP enabled.
For information about using a static IP address, see Fireware Help.
• If your network does not support Power over Ethernet (PoE), connect the optional power adapter
or PoE injector (sold separately).
• Log in to Fireware Web UI and make sure the interface the AP device connects to has DHCP
enabled.
Enable the Gateway Wireless Controller
• Select Network > Gateway Wireless Controller, then select the Enable Gateway
Wireless Controller check box.
• Type the AP Passphrase the Firebox will use for AP devices after they are paired.
Discover and pair the AP device
• Click Refresh to start Access Point discovery.
• Select the discovered Access Point and click Pair.
• Congure radio settings for each radio. Click Save.
Congure an SSID for the AP device
• Select the SSIDs tab. Click Add.
• In the Network Name text box, type a name for this wireless network.
• In the SSID settings, select the Security tab. Congure wireless security settings.
• In the SSID settings, select the Access Points tab. Select the Access Point radios.
• Click Save.
Verify AP device status
• Select Dashboard > Gateway Wireless Controller, then select the Access Points tab.
• Make sure your known AP devices are trusted and the device status is Online.
For complete information about how to congure your AP device with the Gateway Wireless Controller on
your Firebox, see Fireware Help at http://www.watchguard.com/wgrd-help/documentation/overview.
Getting Started with the WatchGuard
Wi-Fi Cloud Video Tutorial (10 minutes)
http://wgrd.tech/2cDXQRM
Use a mobile device
to verify that your new
wireless network is
broadcasting.
HINT:
