OPERATOR’S MANUAL
HBG
■ HBG-15 ■ HBG-30
For tech ni cal as sis tance or the Water Maze Dealer nearest you
visit our web page at www.wmaze.com
8.913-990.0-K10/13/20
L
I
S
T
E
D
®
89139900-1

Table of Contents

Questions and Answers

  • D
    deborah46Aug 17, 2025
    What to do if the burner motor is running but there is no flame in my Water Maze HBG-15 Industrial Equipment?
    • C
      christinelopezAug 17, 2025
      If the burner motor runs but there is no flame in your Water Maze Industrial Equipment, it could be due to several reasons. First, the pilot might be out (HBG-15), in which case you should restart the burner. Second, there might be very low or no gas pressure, so you should adjust the pressure regulator. Finally, the motor might be running too slow, so check the voltage.
  • J
    Joseph DunnAug 20, 2025
    How to troubleshoot a Water Maze HBG-15 Industrial Equipment that won’t power up?
    • C
      craigvazquezAug 20, 2025
      If your Water Maze Industrial Equipment machine won’t power up, it could be due to a tripped breaker. In that case, reset the breaker and reset the batch cycle controller by pushing the F1/RST button. Alternatively, the batch cycle might be complete; if so, reset the batch cycle controller by pushing the F1/RST button.
  • C
    charles95Aug 25, 2025
    What to do if the pilot goes out when the gas valve opens in my Water Maze Industrial Equipment (HBG-15)?
    • T
      Tyler WilsonAug 26, 2025
      If the pilot goes out when the gas valve opens in your Water Maze Industrial Equipment (HBG-15), it might be due to a restriction in the pilot gas line, so you should clean the pilot orifice. Alternatively, there might be high or low gas pressure, so test and adjust the pressure. Excessive pressure drop when the main gas valve opens could also be the cause, in which case you should increase the size of the inlet gas piping.
  • S
    Shirley RodriguezAug 27, 2025
    Why is the burner flame short and noisy in my Water Maze HBG-15?
    • P
      Pamela WoodAug 28, 2025
      If you notice a short, noisy burner flame in your Water Maze Industrial Equipment, it could be because the pressure regulator is set too low; increase the pressure. Another possibility is that the air shutter is open too wide; close the shutter. Too much pressure drop in the gas line could also cause this issue, so increase the gas pipe size. Finally, the regulator itself might be defective, requiring replacement.
  • E
    Eric RobinsonAug 30, 2025
    What to do if the pilot does not light in my Water Maze Industrial Equipment (HBG-15)?
    • P
      Paul HickmanAug 30, 2025
      If the pilot does not light in your Water Maze Industrial Equipment (HBG-15), it could be due to air in the gas line, so you should bleed the gas line. It could also be due to high or low gas pressure, so adjust the air regulator. Another possible cause is a blocked pilot orifice, in which case you should replace or clean the orifice.
  • H
    Heidi SmithSep 2, 2025
    Why is the flame long and yellow in my Water Maze Industrial Equipment?
    • C
      Connie BaileySep 2, 2025
      A long yellow flame in your Water Maze Industrial Equipment can be caused by a few things. First, the air shutter might not be open enough, so open the air shutter. Second, the air openings or blower wheel could be clogged, so clean them. Finally, there might be too much input gas, so turn the gas pressure down.
  • J
    Jennifer NorrisSep 5, 2025
    Why does the pilot go out frequently during standby in my Water Maze Industrial Equipment (HBG-15)?
    • L
      Laura BarrSep 5, 2025
      If the pilot goes out frequently during standby in your Water Maze Industrial Equipment (HBG-15), it could be due to a restriction in the pilot gas line, so clean the line. Low gas pressure could also be the cause, so adjust the pressure regulator. Another possibility is a blocked pilot orifice, in which case you should replace or clean the orifice.
  • K
    Kyle LangSep 7, 2025
    What causes the main gas valve to not close when the blower stops in my Water Maze Industrial Equipment?
    • D
      Dawn FischerSep 7, 2025
      If the main gas valve does not close when the blower stops in your Water Maze Industrial Equipment, it is likely due to a defective valve or an obstruction on the valve seat. In either case, you should replace the gas valve.
  • J
    John JenkinsSep 12, 2025
    Why is the regulator vent leaking gas in my Water Maze HBG-15?
    • W
      wilsonsharonSep 12, 2025
      If you observe the regulator vent leaking gas in your Water Maze Industrial Equipment, it is likely due to a hole in the diaphragm. You should replace the regulator.
  • N
    Nicole DunlapSep 13, 2025
    What causes the burner to ignite for only 2-4 seconds in my Water Maze HBG-15 (HBG-30)?
    • B
      Brian DavisSep 13, 2025
      If the burner ignites for only 2-4 seconds in your Water Maze Industrial Equipment (HBG-30), it might be due to incorrect main voltage polarity. Try switching the black and white incoming power wires.
