Thermostatic Shower with Built-in
Volume Control/ Diverter
Thermostatic Shower Trim w/ Built-in
Volume Control/ Diverter Page | 5
Parts Checklist
Carefully remove all parts from the box.
The following parts should be included.
Description
Qty
1
Face plate
1
2
Lock Ring
2
4
Temperature control
handle post
1
5 Volume control handle
post
1
6 Temperature control
dome
1
Representative Trim
Parts Checklist
7
Volume control dome
1
9
Volume Control handle
1
10 Temperature Control
handle
1
11 Temperature control set
screw (for some models)
1
12
set screw (for some
models)
2
13
Dome sleeve (raw brass)
2
Representative Trim
