WATSON SEVEN Assembly Instructions

4 Seven/Relay Workbench Assembly | INS-SWORKBENCH
Support Rails + Legs
Secure the rails to the legs with M6-
1.0x12mm screws (x8 per leg).
Note — Do not fully tighten the unit until
full assembly of the Raceway, with
surface attached, is complete.
Control Box + Wires
A
Feed the power cable through the rail notch.
B
Secure the power cable to the control box. Loop
power cable into the small arcing groove and press in.
This provides strain relief for the power cord so it does
not come disengaged during use. Place the control box
on the Rail in between the access cutouts.
C
Secure control box in place with
M6-1x40mm Phillips Pan Head Machine
Screw (125293) and M6-1x12mm Nylock
Nut (888152)
D
Plug cords
Underside Shown
1.
2.
B
B
A
C
C
D
D
D
