2
3. Once the plastic connectors are attached, the Pro Port may be aligned with the C-channels and then
moved forward to attach the port to the connectors. Place the blue connecting pin into the opening as
shown below and through the hole in the plastic connector. Secure the pin with the shoulder bolt and
washer. Tighten securely. Repeat on the other side.
Shoulder bolt and washer attach here.
Push blue connecting pin through these
holes once the parts are aligned.
Completed unit.
