The following table describes the electrical characteristics of the interface.
Some signals require particular connections and are specified in bold
characters.
Pin #
Pin #Pin #
Pin # Name
NameName
Name I/O
I/OI/O
I/O I/O type
I/O typeI/O type
I/O type Description
DescriptionDescription
Description Comment
CommentComment
Comment
1 GND GROUND High current
2 GND GROUND High current
3 +5V I Supply High current
4 +5V I Supply High current
5 CT109/DCD O CMOS/2X RS232-Data Carrier
Detect
6 GND GROUND High current
7 GPIO2 I/O CMOS/2X General Purpose I/O
8 SPK2N O Analog Speaker2 negative
output
9 CT125/RI O CMOS/2X RS232-Ring Indicator
10 SPK2P O Analog Speaker 2 positive
output
11 GPIO1 I/O CMOS/2X General Purpose I/O
12 SPK1P O Analog Speaker 1 positive
output
13 CT106/CTS O 1X RS232 interface Clear
To Send
14 SPK1N O Analog Speaker 1 negative
output
15 ON/~OFF I Power ON/OFF control
16 MIC2P I Analog Microphone 2 positive
input
17 AUXV0 I Analog Auxiliary ADC input
18 MIC2N I Analog Microphone 2 negative
input
19 ~RST
~RST~RST
~RST I Reset active low Open Collector
Open CollectorOpen Collector
Open Collector
20 MIC1P I Analog Microphone 1 positive
input
21 GND
GNDGND
GND I Ground
22 MIC1N I Analog Microphone 1 negative
input
23 BOOT
BOOTBOOT
BOOT I BOOT Open Collector
Open CollectorOpen Collector
Open Collector
24 GND GROUND High current
25 CT103/TX
CT103/TXCT103/TX
CT103/TX I RS232 interface -
Transmit
Pull up to VCC
Pull up to VCCPull up to VCC
Pull up to VCC
with 100K
with 100Kwith 100K
with 100KΩ
ΩΩ
Ω
when not used
when not usedwhen not used
when not used
26 GPIO0 I/O CMOS/2X General Purpose I/O
27 CT107/DSR O 1X RS232 interface
Data Set Ready
28 CT104/RX O 1X RS232 interface –
Receive
