Game HAT User Manual
OTHER COMMON OPERATIONS
For more operations, you can read Retropie Instructions
PINS (LCD)
If the pins which are note with NC it means that the pins is not used by LCD, you can
use them for other usage.
PIN
Identity
Description
1
3.3V
3.3V power input
2
5V
5V Power input
3
NC
NC
4
5V
5V power input
5
NC
NC
6
GND
Ground
7
Select
BCM=4，WPI=7
8
NC
NC
9
GND
Ground
10
NC
NC
11
NC
NC
12
TL
BCM=18，WPI=1
13
NC
NC
14
GND
Ground
15
NC
NC
16
TR
BCM=23，WPI=4
17
3.3V
3.3V power input
18
NC
NC
