Game HAT User Manual
19
NC
NC
20
GND
Ground
21
NC
NC
22
NC
NC
23
NC
NC
24
NC
NC
25
GND
Ground
26
NC
NC
27
NC
NC
28
NC
NC
29
UP
BCM=5，WPI=21
30
GND
Ground
31
DOWN
BCM=6，WPI=22
32
B
BCM=12，WPI=26
33
LEFT
BCM=13，WPI=23
34
GND
Ground
35
RIGHT
BCM=19，WPI=24
36
X
BCM=16，WPI=27
37
A
BCM=26，WPI=25
38
Y
BCM=20，WPI=28
39
GND
GND
40
START
BCM=21，WPI=29
