SPECIFICATIONS
FG2C FG3C
1.Main
Frequency Range 0.3 Hz to 3 MHz (7 Range) 0.3 Hz to 3 MHz (7 Range)
Amplitude >10Vpp (into 50Ω load) >10Vpp (into 50Ω load)
Impedance 50Ω ±10% 50Ω ±10%
Attenuator -20dB ±1dB x2 -20dB ±1dB x2
DC Offset <-5V to >+5V (into 50Ω load) <-5V to >+5V (into 50Ω load)
Duty Cycle Control 80%:20%:80% to 1MHz Continuously variable 80%:20%:80% to 1MHz Continuously variable
LED Display N/A 6 digits; 7.6mm (0.3 in) high
Range Accuracy ±5% +1 Hz (at 3.0 position) N/A
2.Sine Wave
Distortion ≤1 %, 0.3 Hz to 200 kHz ≤1 %, 0.3 Hz to 200 kHz
THD ≤35dB below fundamental in all ranges THD ≤35dB below fundamental in all ranges
(Specification applied from MAX. to 1/10 level) (Specification applied from MAX. to 1/10 level)
Flatness < 0.3dB, 0.3 Hz to 300 kHz < 0.3dB, 0.3 Hz to 300 kHz
< 0.5dB, 300 kHz to 3 MHz < 0.5dB, 300 kHz to 3 MHz
3.Triangle Wave
Linear ≥ 98 %, 0.3 Hz to 100 kHz ≥ 98 %, 0.3 Hz to 100 kHz
≥ 95 %, 100 kHz to 3 MHz ≥ 95 %, 100 kHz to 3 MHz
4.Square Wave
Symmetry ±2%, 0.3 Hz to 100 kHz ±2%, 0.3 Hz to 100 kHz
Rise or Fall Time ≤ 100ns at maximum output. ≤ 100ns at maximum output.
(into 50Ω load) (into 50Ω load)
5.CMOS Output
Level 4Vpp ±1Vpp to 14.5Vpp 4Vpp ±1Vpp to 14.5Vpp
±0.5Vpp adjustable ±0.5Vpp adjustable
Rise or Fall Time ≤ 120ns ≤ 120ns
6.TTL Output
Level ≥ 3Vpp ≥ 3Vpp
Fan Out 20 TTL load 20 TTL load
Rise or Fall Time ≤ 25ns ≤ 25ns
7.VCF
Input voltage 0 to 10V ±1V(100:1) 0 to 10V ±1V(100:1)
Input Impedance 10kΩ ±10% 10kΩ ±10%
8.GCV
Output voltage N/A To set the voltage between
0 to 2V as per different frequency.
