Wavin Osma StormLine PVC-U Rainwater Systems
28 www.wavin.co.uk
Gutter
StormLine Gutter
Material:PVC-U
Nominal Part Colour Length
Size (mm) Number Option (m)
111x76x97 8T874
l l
4
Gutter Union and Brackets
A
Gutter Jointing Bracket
Material:PVC-U,withEPDMseals
Nominal Part Colour Dimensions (mm)
Size (mm) Number Option A
111x76x97 8T809a
l l
100
A
B
Gutter Support Bracket
• For support centres, see page 54
Material:PVC-U
Nominal Part Colour Dimensions (mm)
Size (mm) Number Option A B
111x76x97 8T819a
l l
100 117
A
B
Gutter Hanging Bracket
• Forunobtrusivexing,almostinvisiblefromgroundlevel
• For support centres, see page 54
Material:PVC-U
Nominal Part Colour Dimensions (mm)
Size (mm) Number Option A B
111x76x97 8T849
l l
80 125.5
Gutter Bracket Spacer – 21mm Projection
• Use with Gutter Brackets 8T819 or 8T849 to provide additional 21mm
clearance
Material:PVC-U
Nominal Part Colour Dimensions (mm)
Size (mm) Number Option A B
– 0T044
l
103 21
